V-Series Hand Cutting Tip – Model V3-101-0

Description

Model V3-101 is a single-piece acetylene tip for hand cutting torches.

• Model V3-101-0 V-Series® general preheat single-piece hand cutting tip for use with acetylene
• Model V3-101 is a single-piece acetylene tip for hand cutting torches.
• Single-piece copper hand cutting tip
• General preheat
• For use with acetylene
• Cuts relatively clean steel
• Compatible with V-Series® torches
• Typical applications include construction, maintenance, metal art, etc.
• Marked with model number and tip size for easy identification
• Model V3-101-0 V-Series® Hand Cutting Tip
• 1 Year
• V3-101-0
• Harris
• Acetylene

• Acetylene PSIG (Min. – Max.): 7
• Compatible Cutting Attachment Model Number: V-1350;VH13
• Compatible Handle Model Number: V-100C-2;VH10
• Construction: One piece – Copper
• Cutting Depth: 5/16 in. – 5/8 in. (7.9mm – 15.9mm)
• Cutting Drill Size: No. 61
• Gas / Gas Service: Acetylene
• Oxygen PSIG (Min. – Max.): 30 – 40
• Preheat Type: General
• Recommended Items/Accessories: Standard One-Piece Tip Cleaner – Model C-9 – PN 9000156
• Style: Hand cutting
• Tip Size / Number: 0
• Typical Application: Maintenance;Metal art;Construction

What’s Included: Model V3-101-0 V-Series® Hand Cutting Tip

Model Name: V3-101-0
